Eclipse Magnetics
Eclipse Ultralift E Magnetic Lifter
- SKU:
- P-MAGULE0100
Description
The Cost-Effective Choice For High Performance Lifting
Our brand new Ultralift E Magnetic Lifter range utilises the latest in magnetic technology to provide a cost-effective lifting solution. The technology is fail-safe, extremely easy to operate, with no electricity required delivering world class results when handling ferrous loads compared to traditional methods such as slings, chains, hooks and grabs.
With a guaranteed Working Load Limit (WLL) of 3:1, you can rest assured that the Ultralift E provides a safe and efficient way to lift ferrous loads in your factory, workshop or warehouse.
High Performance Lifting Magnet For Ferrous Loads
Our Ultralift E Magnetic Lifter range is ideal for applications ranging from light pick and place equipment to heavy steel stock movement. This high performance magnetic lifter has been designed with safety uppermost in mind, in addition to utilising permanent magnetic technology to ensure the load cannot be released during lifting. A secondary handle locking device provides further re-assurance that the load cannot be accidentally released when in use.
| Product Number | Self Weight (kg) | Material Length Max. (mm) | Flat Section WLL (kg) | Flat Section Thickness Min (mm) | Round Section Dia. Max (mm) | Round Section WLL (kg) |
|---|---|---|---|---|---|---|
| ULE0100 | 3 | 1000 | 100 | 15 | 80 | 50 |
| ULE0300 | 10 | 1500 | 300 | 20 | 100 | 150 |
| ULE0600 | 23 | 2000 | 600 | 30 | 140 | 300 |
| ULE1000 | 39 | 2500 | 1000 | 40 | 180 | 500 |
| ULE2000 | 74 | 3000 | 2000 | 50 | 300 | 900 |
